N2 Gas Semi-Automatic Parallel Seam Sealer
N2 Gas Semi-Automatic Parallel Seam Sealer
It is a semi-automatic seam sealing equipment that hermetically seals packages such as crystal & SAW devices, optical devices, sensors, and MEMS in N2 atmosphere.
This parallel seam sealer can handle various package shapes including rectangular, circular, and polygonal shape of 2-150mm size.
- Various Operation modes available for R&D and mass production.
- PKG size 2~150mm - Rectangular,round,polygon.
- Easy Operation & Programming
- Automatic program verification
Single head type Semi-Automatic Parallel Seam Sealer
Features
Seam sealing power supply
- Dedicated seam sealing power supply developed in-house
- High speed and suppression of thermal effects
Up slope and down slope electric current control function.
Monitoring function is equipped.
High performance head
- Lightweight head (Min. 300gf)
- Soft landing mechanism
Production mode
- Standard mode
- Fast mode
- Teaching mode
Vacuum Oven Chamber
- Large capacity chamber： Increased productivitye
- High-precision heating： Improved reliability
Parallel Seam Sealer Specifications
| Semi-Automatic Parallel Seam Sealer | Single head type | |
|---|---|---|
| NAW-1105 series | NAW-2050 series | |
| Rated capacity of welding power supply | 2kVA | 4kVA |
| Pressure | 2～9.5N | 3～18N |
| Applicable lid thickness | MAX 0.12mm | MAX 0.3mm |
| N2 Gas | 0.2～0.8MPa | |
| Water | 0.2～0.5MPa 5L/min | |
| Power Source | AC200V 3Φ 20A | AC200V 3Φ 30A |
| Dimensions | 2200W × 940D × 1570H mm | |
| Mass | ≒450kg | ≒480kg |
Twin head type Semi-Automatic Parallel Seam Sealer
Features
- PKG size 2~10mm / Rectangular
- Production mode / Standard mode / Fast mode
- Automatic program verification
Parallel Seam Sealer Specifications
| Semi-Automatic Parallel Seam Sealer | Twin head type |
|---|---|
| NAW-1275seriesad type | |
| Rated capacity of welding power supply | 2kVA |
| Pressure | 2～9.5N |
| Applicable lid thickness | MAX 0.12mm |
| N2 Gas | 0.2～0.8MPa |
| Water | 0.2～0.5MPa 5L/min |
| Power Source | AC200V 3Φ 30A |
| Dimensions | 2730W×880D×1280H mm |
| Mass | ≒750kg |
